Special jaws / Boring rings / Cleaning plate / Gripping force tester / Repair service / Calculations
GM
Jaw mounting bolts
GF
Jaw mounting bolts
- ISO 4762, Class 12.9
- For base jaws type GBK, GBK-2G GBKS, GBK-B, GBK-B-2G, MFG
RPS
Dress and cleaning plate
Dress and cleaning plate
- Inch and metric serration
- To clean and dress top jaws
Repair service
Repair service
Repair service
- Refurbishing of the clamping area and or the serration of worn out jaws
GRIPPERS UGE FGH + HDS CLAMPING TIPS MGH
Grippers and Clamping tips
Grippers, special steel hardened-Grippers carbide, clamping tips
PRECISION GRIPPER G14 + G25
Grippers
Precision gripper controlled penetration
- With pull down effect
PRECISION GRIPPER G15 + G30
Grippers
Precision gripper controlled penetration
- For highest torque transmission
ADVL
Light duty version
ADVS
Heavy duty version
Bore fixture to bore jaws on the chucks, ADVL to low grip force, ADVS to high grip force mainly used on power chucks
- To bore soft or quenched jaws
- Adjustment of the clamping diameter by turning the scroll or reversing the inserts
- ADVS: to grind hard jaws on manual and power chucks
- The fixture can cover a large range
BORING RINGS ADS
Boring rings
Boring rings to bore jaws on the clamping chuck
- Complete set to bore all diameters from 20 to 150 mm
- Set consisting of 36 rings Ø 20-50 mm each stepped 2 mm
- Clearly organized in packing box
- Rings from Ø 105 mm and up have 3 tapped holes for clamping bolts to machine jaws for internal gripping
- Rigid design. Rings are 10 mm thick, quenched for greater durability
- Loading tool is used for the safe insertion of the rings without danger of injuries
DRESS AND CLEANING PLATE RPS
Dress and cleaning plate
Dress and cleaning plate RPS for dressing and cleaning of top jaw serrations
- 2 different serrations per plate (upper and lower side)
GFT-X 4.0
Gripping force tester
Gripping force tester GFT-X 4.0 multi device tablet with expert apps
- Wireless handheld with rechargeable battery
- Dynamic or static gripping force measuring
- Speed measuring
- Display Software
