Universal 4 Grippers
size 100 - UNIVERSAL GRIPPERS long stroke
L=long stroke
4PXS-L
4 jaws self-centering grippers pneumatics
- Aluminium body to contain the gripper weight
- Functional parts heat-treated for high precision and long life
- Jaws with calibrated bushings
- Protection class IP40
- Highest rigidity and Repeatability: 0,01 mm
- Prepared for Air purge
size 125 - UNIVERSAL GRIPPERS long stroke
L=long stroke
4PXM-L
4 jaws self-centering grippers pneumatic and protected
- Aluminium body to contain the gripper weight
- Functional parts heat-treated for high precision and long life
- Master jaws with calibrated bushings
- Protection class IP40
- Highest rigidity and Repeatability: 0,01 mm
- Prepared for Air purge
size 160 - UNIVERSAL GRIPPERS long stroke
L=long stroke
4PXM-L
4 jaws self-centering grippers pneumatic and protected
- Aluminium body to contain the gripper weight
- Functional parts heat-treated for high precision and long life
- Master jaws with calibrated bushings
- Protection class IP64
- Highest rigidity and Repeatability: 0,01 mm
- Prepared for Air purge
size 200 - UNIVERSAL GRIPPERS long stroke
L=long stroke
4PXM-L
4 jaws self-centering grippers pneumatic and protected
- Aluminium body to contain the gripper weight
- Functional parts heat-treated for high precision and long life
- Master jaws with calibrated bushings
- Protection class IP64
- Highest rigidity and Repeatability: 0,02 mm
- Prepared for Air purge
